a). Floor mounted C-arm
b). Image Intensifier
c). XIMS hemodynamic system
a). Flat Panel detector
b). Floor mounted C-arm
c). Compact and slim line C-arm design
d). Dynavision - Rotational angio feasibility
f). Table tilt possibility
g). Axiom Sensis hemodynamic system
h). Conciderable radiation reduction with CARE
i). SYNGO IC3D - Fast and accurate method for lesion analysis using a 3D morphological model of coronary vessel
j). Excellent image quality through CLEAR technology
a). Allura Xper Flat Panel Detector 10
b). Celing mounted C-arm
c). Xtravision hardware with Stentboost
d). XIMS hemodynamic System
e). DSA limited frame rate
f). 184 micropixel for higher resolution and superb image quality
g). Low dose Fluroscopy
a). PRO EP_ recording system
b). Patient Review mode provides significant improvements to workflow
c). CLEARSIGN Amplifier provides excellent signal quality with unique noise filtering and up to 160 intracardiac channels
d). Patient Data archiving
Model EE 3000: Ensite Version 6
The Ensite System is an advanced mapping and catheter navigation system, capable of displaying cardiac electrical activity is waveform traces and as dynamic three-dimensional iso potential maps of the cardiac chamber.
The contoured geometry of the three dimensional maps is based on the patients own cardiac chamber .Using the 3D map. the Ensite navigation system displays the three dimensional position of conventional electrophysiological catheter.
When Ensite System is used in conjunction with ensite Array, the System can collect, store and display over 3000 intracardiac electrogram without the need to manipulate the conventional EP catheters in cardiac chamber
Intravascular Ultrasound (IVUS) is a catheter based system that allows physicians to acquire images of diseased vessels from inside the artery.IVUS utilizes acoustic impedence of vascular structures to provide cross sectional image from inside vessel .
The IVUS catheter uses a transducer near the distal tip to emit and receive high frequency ultrasound IVUS provides detailed and accurate measurements of lumen and vessel size, plaque area and volume, and the location of key anatomical landmarks.
Volcano's proprietary VH® IVUS technology helps differentiate the four plaque types: fibrous, fibro-fatty, necrotic core and dense calcium
Measures intravascular blood pressure and blood flow velocity in all blood vessels, including the coronary and peripheral arteries during diagnostic and interventional procedures.
The Rotablator -Rotational Angioplasty system is a catheter based device utilizing a diamond coated elliptical burr at the tip of flexible drive shaft. Tracking co-axially over a guide wire and rotating at up to 190000 rpm the burr ablates calcific plaques into fine particles that are disposed by body's reticuloendothelial system.
a) Intelli-sense combines fiber-optic speed with automatic in vivo calibration. The result is faster time to therapy, faster signal acquisition and faster adaptation to rate and rhythm changes.
b) Automated evaluation of best lead and trigger source
c) Has one button start up
